Dimensions | Diameter: 53 mm, length: 213 mm |
Weight | 700 g without cable, 1.8 kg with cable and plug |
Output | 1.4 kW – 11 kW AC |
Rated current | 6 A to 16 A |
Voltage | 230 V (1-phase) / 400 V (3-phase) |
Material, colour | Anodised aluminium, anthracite |
Operating temperature | -30 °C to +50 °C |
CE-conformity | IEC 62752, 62196, 61851-1, mode 2/3, EMV, RoHS |
Protection class – residual current – safety | IP67 – RCD DC 6 mA, AC 30 mA – protective conductor and temperature monitoring |
Mains plug | More than 30 self-detecting adapters available for domestic, industrial and EV sockets, 1.4 m lead + approx. 30 cm adapter |
Vehicle side connection | Type 2 (EN 62196) / type 1 (SAE J1772) cable length 3.1 m |
