Dimensions | 280 x 280 x 125 mm |
Weight | 6.5 kg |
Input current | 230 V, 6 – 32 A (1-phase) AC or 400 V, 6 – 32 A (3-phase) AC |
Power output | 11 kW (16 A, 3-phase); adjustable to 22 kW (32 A, 3-phase) |
Residual current device (RCD) | RCD DC 6 mA integrated |
Communication | OCPP 1.5/1.6, Modbus TCP, EEBUS Ethernet interface (LAN, RJ45 connection) |
Activation | RFID reader for access control (MIFARE Classic/Desfire) The RFID frequency is 13.56 MHz. |
Charging/load management | Configurable for master and slave operation (up to 250 units), load shedding via floating contacts |
Safety | Internal temperature sensor for reducing the charging current independently of the environmental temperature |
Protection class | IP67 |
Impact resistance | IK10 |
Operating temperature | -30° C to +50° C |
